Expanding and assigning parameters to the device
6.3 Installing and removing M.2 NVMe/ SATA SSD
SIMATIC IPC277G
56 Operating Instructions, 08/2021, A5E50059956-AA
Place the M.2 NVMe/SATA SSD in the slot and secure it with
the designated screw.
Note: Keep the Key M notch on the left side of the module
as shown in the image.
Plug in the slot back into the device and tighten it with
designated screws.
Procedure - removing the M.2 NVMe/SATA SSD
To remove the M.2 NVMe/SATA SSD, carry out the steps for installing the M.2 NVMe/SATA
SSD in the reverse order.
