Technical specifications
8.4 Technical data
SIMATIC IPC377G
74 Operating Instructions, 07/2022, A5E51366314-AB
Drive, memory medium
Slot X103: support NGFF M.2 2230/2242/2280 with Key M/Key
B+M
• Without drive
• 256GB SSD
• 512 GB SSD
External, can be connected via USB port
Graphics
Intel® Integrated UHD Graphic Controller
• 12" screen diagonal with backlighting,
resolution 1280 × 800 pixels
• 15" screen diagonal with backlighting,
resolution 1366 × 768 pixels
• 19" screen diagonal with backlighting,
resolution 1366 × 768 pixels
• 22" screen diagonal with backlighting,
resolution 1920 × 1080 pixels
Touch controller Resistive touch controller ETP-CP-MER4485XRU
• Touch screen analog resistive
• Touch force with R0.8 Delin stylus pen, at 250g forces
Backlighting (MTBF)
Half brightness lifetime, typical
LCD
min. 50000 h at 25 °C, 50% brightness
Pixel error class in accordance with
ISO 9241-307
Interfaces
2 × Gigabit Ethernet interface (two RJ45) electrically isolated
Wake on LAN and Remote Boot are supported:
• X1P1: Marwell 88E1512
• X2P1: Marwell 88E1512
• COM1/2: RS232/RS422/RS485
1
(switchable), D-sub connector, 9-pin
• COM3/4: RS232 (optional), max. 115 Kbps, D-sub connector, 9-pin
USB On the interface panel:
• 4 × USB 3.1 (900mA)
On the Motherboard:
• 1 × USB pin header (2 USB 2.0 ports)
• 1 × USB 2.0 type A connector (USB dongle)
You can find additional information in the section "Power demand of the
