Expanding and assigning parameters to the device
5.5 Disk drive
SIMATIC IPC527G
44 Operating Instructions, 03/2019, A5E45491226-AA
Procedure - Removing the disk drive
Pull out the connection plug.
Lay down the device's rear panel including the
drive.
Remove the indicated screws.
Procedure - Installing the disk drive
Follow the steps in reverse order to install the disk drive.
