Siemens Simatic IPC527G - Environmental Conditions

Technical specifications
7.4 Technical data
SIMATIC IPC527G
Operating Instructions, 03/2019, A5E45491226-AA
65
7.4.2
Environmental conditions
Climatic ambient conditions
For permitted mounting positions, see section Preparing for installation (Page 17).
Temperature, tested in accordance with IEC 60068-2-1, IEC 60068-2-2 and IEC 60068-2-14
Operation, PCIe load max. 45 W, USB load
max. 20 W, M.2 card load max. 3 W:
0 °C to +40 °C applies to device for all permitted
mounting positions for HDD configuration
0 °C to +45 °C applies to device for all permitted
mounting positions for SSD configuration
Temperature during storage/transport
-20 °C to +60 °C
Gradient
• Operation: Max. 10 °C/h
• Storage: 20 °C/h, no condensation
Relative humidity
, tested in accordance with IEC 60068-2-78, IEC 60068-2-30
Operation 8% to 85% at 30 °C, no condensation
Gradient ≤ 10℃/h
Storage/transport 8% to 90% at 25/55 °C, no condensation
Gradient ≤ 20℃/h
Atmospheric pressure
Operation 1080 to 795 hPa, corresponds to an altitude of -1000
to 2000 m
Storage/transport 1080 to 660 hPa, corresponds to an altitude of -1000
to 3500 m
Altitude of operation (m)
Up to 2000 m
Pollution Degree
2
Mechanical ambient conditions
Vibration resistance, tested in accordance with IEC 60068-2-6
Operation With HDD :
• 10 to 58 Hz: 0.015 mm
• 58 to 200 Hz: 1.96 m/s²
With SSD :
• 10 to 58 Hz: 0.0375 mm
• 58 to 200 Hz: 4.9 m/s²
Storage/transport
• 5 to 8.4 Hz: 3.5 mm
• 8.4 to 500 Hz: 9.8 m/s
2
Shock resistance, tested in accordance with IEC 60068-2-27
Operation
• With HDD: 9.81 m/s
2
, 20 ms
• With SSD: 150 m/s², 11 ms
Storage/transport
• 250 m/s
2
, 6 ms
