Technical specifications
7.4 Technical data
SIMATIC IPC527G
62 Operating Instructions, 03/2019, A5E45491226-AA
7.4
Technical data
7.4.1
General technical specifications
General technical specifications
Weight with hard disk drive, with-
out mounting brackets
Approx. 5.0 kg
Power supply
1
• 100 V AC to 240 V AC (-10%, +10%); 4 A to 8 A
• Frequency: 50 to 60 Hz
• Rated output power: 350W (+5 V & +3.3 V≤91 W)
Power consumption (DC)
• Full load (100%, 350 W) at 82% efficiency
• Typical load (50%, 175 W) at 85% efficiency
• Light load (20%, 70 W) at 82% efficiency
Noise emission
< 55 dB(A) according to DIN 45635-1
Degree of protection IP20
in accordance with IEC 60529
Protection class
Protection class I in accordance with IEC 61140
Overvoltage Category
II
Quality assurance
In accordance with ISO 9001
Electromagnetic compatibility
Radiation Emission (Enclosure
port)
in accordance with IEC 61000-6-3
+ A1/ EN61000-6-4+A1
• 30 - 230 MHz: 40 dB(µV/m) Quasi-peak (10 m distance)
• 230 -1000 MHz: 47 dB (µV/m) Quasi-peak (10 m distance)
• 1- 3 GHz: 76 dB (mV/m) Peak; 56 dB (mV/m) Average (3 m
distance)
• 3- 6 GHz: 80 dB (mV/m) Peak; 60 dB (mV/m) Average (3 m
distance)
Immunity with regard to conducted
interference on the supply lines
± 2 kV / 5 kHz / 100 kHz in accordance with IEC 61000-4-4;
Burst
± 1kV line to line, ±2 kV line to earth in accordance with IEC
61000-4-5; Surge
Noise immunity on signal lines Burst:
± 1 kV / 5 kHz /100 in accordance with IEC 61000-4-4; Length of
signal port extension cable < 30 m;
± 2 kV / 5 kHz /100 in accordance with IEC 61000-4-4; Length of
signal port extension cable ≥ 30 m
Surge:
± 1 kV line-to-line; ± 2 kV line-to-earth in accordance with IEC
61000-4-5; Length of signal port extension cable ≥ 30 m
