Overview
1.1 Product description
SIMATIC IPC527G
8 Operating Instructions, 03/2019, A5E45491226-AA
1.1.1
Configuration plan
Mounting The device supports the following four mounting types:
• Desk mounting
• Wall mounting
• Book mounting
• Tower mounting
Chipset
• Intel® H110
Processor
• Intel® Pentium® Processor G4400 (3M Cache, 3.30 GHz)
• Intel® Core™ i5-6500 Processor (6M Cache, up to 3.60 GHz)
• Intel® Core™ i7-6700 Processor (8M Cache, up to 4.00 GHz)
Main memory Memory expansion up to 16 GB with the following memory modules (without ECC), support
of 32 GB (2 × 16GB) possible:
• 4G DDR4 SDRAM
• 8G DDR4 SDRAM
• 16G DDR4 SDRAM
Possible of extendability
• 1 × PCIe ×16 slot;
• 1 × PCIe ×16 slot, 1 × PCIe ×1 slot, 2 × PCI slot (with riser card)
.
Graphics
• Integrated Graphic Controller
• 1 × VGA(DB-15) + 1 × DP(DDI)
• VGA support max to 1920 × 1200 pixels
• DP support max to 4K
Power supply 100 V AC to 240 V AC (-10%, +10%)
Drives and storage media
Hard Disk Drive (HDD),
optional
1 TB, 2.5" HDD SATA
Solid State Drive (SSD),
optional
• 128 GB, 2.5" SSD SATA
• 256 GB, 2.5" SSD SATA*
• 512 GB, 2.5" SSD SATA*
M.2 Solid State Driver
M.2 2242 Key B slot
USB stick
Can be connected externally through USB port and internally
Interfaces
Ethernet
• 2 × RJ45 Ethernet 10/100/1000 Mbps
• 2 × RJ45 Ethernet 10/100/1000 Mbps +1 × RJ45 Ethernet 10/100/1000 Mbp (1 PCIe slot
occupied)
COM
• 2 × RS232 /RS422 /RS485
• 2 × RS232 /RS422 /RS485 + 2 × RS232
USB (external)
• 4 × USB 3.0 (900mA)
• 4 × USB 3.0 (900mA)+ 2 × USB 2.0 (500mA)
USB (internal)
1 x USB 2.0 vertical (500 mA) for internal USB stick/dongle
