Technical specifications
7.4 Technical data
SIMATIC IPC527G
64 Operating Instructions, 03/2019, A5E45491226-AA
Drive, memory medium
Hard disk drive, optional
1 TB HDD, support of 2 × 2.5" HDD SATA, 500 GB- 2TB
Solid State Drive, optional
128 GB SSD, support of 2 × 2.5" SSD SATA, 64 GB- 1TB
M.2 Solid State Driver, optional
Support of 32-256GB, M.2 2242 SSD
Floppy and CD-ROM drive
External, can be connected via USB port
1
USB stick External, can be connected via USB port
1
Only to device USB port, not via USB hub.
Graphics
Graphics controller
Integrated Graphic Controller
Resolution, graphics memory
• at least support 2 channels: 1 × VGA(DB-15) + 1 × DP(DDI)
• VGA support max to 1920 × 1200 pixels
• DP support max to 4K
Ports
Ethernet 2 × Gigabit Ethernet interface (two RJ45) electrically isolated,
Wake on LAN, Remote Boot and teaming are supported:
• X1P1: Intel i210AT
• X2P1: Intel i210AT
1 × Gigabit Ethernet interface (RJ45) optional (through PCIe card):
• Intel i210 T1
COM1/2
RS 232 /RS 422 /RS 485
1
(optional), max. 115 Kbps, D-sub connector, 9-pin
COM3/4 (On mother-
board)
RS 232, max. 115 Kbps, D-sub connector, 9-pin (extension from internal pin
header)
USB
• 2 × USB 2.0 (500mA) (extension from internal pin header)
• 4 × USB 3.0 (900mA)
USB (On mother-
board)
1 x USB 2.0 vertical (500 mA)
VGA
Connection of an analog monitor
DP
Connection of a digital monitor
DIO (Digital Input
Output)
DB9 connector (extension from internal pin header)
Digital Input (5V TTL) and Output (5V 12mA)
Keyboard, mouse
Connection via USB port
1
In BIOS Setup, you can configure support for RS 232/ RS 422/ RS 485 for COM1 and COM2
ports.
