Configuring with Web Based Management
5.4 "Information" menu
SCALANCE W760/W720 to IEEE 802.11n Web Based Management
Configuration Manual, 11/2014, C79000-G8976-C350-03
63
The following is available in the selection area:
● Logo of Siemens AG
● Display of: "System Location/System Name".
– "System Location" contains the location of the device.
With the settings when the device ships, the IP address of the Ethernet interface is
displayed.
– "System Name" is the device name. With the settings when the device ships, the
device type is displayed.
You can change the content of this display with "System > General > Device.
● Drop-down list for language selection
● System time and date
You can change the content of this display with "System > System Time.
In the left-hand part of the display area, the full title of the currently selected menu item is
always displayed.
●
Shows whether the device is an access point or a client.
●
When you click this button, a popup window opens with a view of the page content
optimized for the printer.
●
When you click this button, the help page of the currently selected menu item is opened
in a new browser window.
●
Each component of a device has one or more LEDs that provide information on the
operating state of the device. Depending on its location, direct access to the device may
not always be possible. Web Based Management therefore displays simulated LEDs.
Unoccupied slots or unused connectors are displayed as a grayed-out LED. The meaning
of the LED displays is described in the compact operating instructions.
If you click this button, you open the window for the LED simulation. You can show this
window during a change of menu and move it as necessary. To close the LED simulation,
click the close button in the LED simulation window.
