Configuring with Web Based Management
5.4 "Information" menu
SCALANCE W760/W720 to IEEE 802.11n Web Based Management
64 Configuration Manual, 11/2014, C79000-G8976-C350-03
●
WBM pages with overview lists can also have the additional "Update" button.
With this button, you can enable or disable updating of the content area. If updating is
enabled, the display is updated every 2 seconds. To disable the update, click "On".
Instead of "On", "Off" is displayed. As default, updating is always enabled on the WBM
page.
In the navigation area, you have various menus available. Click the individual menus to
display the submenus. The submenus contain pages on which information is available or
with which you can create configurations. These pages are always displayed in the content
area.
In the navigation area, click a menu to display the pages of the WBM in the content area.
The following is displayed below the picture of the device:
● PNIO Name of Station: PROFINET IO device name
● System Name: System name of the device
● Device Type: The type of the device
● PNIO AR Status: PROFINET IO application relation status
● Power Line1, Power Line2: Status of the power supplies Line 1 and Line 2. Power Line 2
is only displayed if it supports the relevant hardware. You will find further information on
this in the compact operating instructions.
● Fault Status: Error status
