Configuring with Web Based Management
5.6 "Interfaces" menu
SCALANCE W760/W720 to IEEE 802.11n Web Based Management
Configuration Manual, 11/2014, C79000-G8976-C350-03
171
●
"Country Code" drop-down list
From this list, you select the country in which the device will be operated.
You do not need to know the data for the specific country, the channel division and output
power are set by the device according to the country you select.
Note
Locale setting
The correct country
setting is mandatory for operation complying with the approvals.
Selecting a country different from the country of use can lead to legal prosecution.
●
"Device Mode" drop-down list
Select the mode of the device. This selection is available only for access points.
The following operating modes are possible:
– AP: Access point mode
– Client: Client mode
Note
After changing the mode, a message is displayed. If you confirm the message with
"OK", the device restarts in the changed mode with the factory
-set configuration
If you have restarted the device after changing the mode, you will need to log on again to
be able to continue the configuration.
The table has the following columns:
●
Shows the available WLAN interfaces in this column.
●
Status of the WLAN interface. To enable the WLAN interface, select the check box.
Note
Enabling the WLAN interface
The WLAN interfaces are disabled when the device is supplied. The WLAN interfaces are
can be enabled once the country and the antenna settings
are configured.
●
Shows the mode of the WLAN interface.
