Configuring the Computing Unit in BIOS Setup
Release 04/02
5-15
Panel PC 670 Computing Unit, Equipment Manual
5.1.2 Menü Advanced
Menu structure
PhoenixBIOS Setup Utility
Item Specific Help
ESC Exit
Reset Configuration Data:
Select Item
Select Menu
+ / –
Select
Change Values
Sub-Menu
F9
F10
Setup Defaults
Save and Exit
COM/LPT Configuration
Floppy disk controller: [Enabled]
[ No ]
Select the operating
system installed
on your system which
you will use most
commonly.
Note: An incorrect
setting can cause
some operating
systems to display
unexpected behavior.
Enter
Help
F1
Security Power Boot Sequence Version ExitMain
Large Disk Access Mode: [DOS]
Local Bus IDE adapter: [Both]
Advanced
Memory Gap at 15 Mbyte: [Disabled]
Video Adapter Settings
Installed O/S:
[ Other ]
PCI Configuration
Setup Warning
Setting items on this menu to incorrect values may
cause your system to malfunction
Figure 5-9 “Advanced” Menu
Settings of the Advanced menu
Installed O/S Plug and Play means that all modules are automatically detected and
installed, providing they support the Plug and Play functionality.
[other] BIOS handles the entire Plug and Play capability, default
configuration
[Win98] The operating system handles some of the
Plug and Play functions
Reset
Configuration
Data
[Yes] means that all previous Plug and Play
are deleted. During the next system booting procedure the
configuration will be started again. The entry is then reset to
[No]. System components that do not support Plug and Play
have to be entered manually.
Floppy disk
controller
Enables or disables the floppy-disk controller on the motherboard.
Local Bus IDE
adapter
[Primary] One IDE interface for max. two drives.
[Secondary]
[Both] Two IDE interfaces for max. four drives.
[Disabled] No local IDE interface.
