Panel PC 670 Computing Unit, Equipment Manual
Distributed configuration
Chapter Overview
This chapter describes all specifications of the distributed configuration that are
different from those of the integrated configuration (described in chapters 2 – 7).
Where this manual focuses on the computing unit.
Note
The part of the description referring to the Remote mount of the control unit will be
found in ”SIMATIC Panel PC 670/870 Control Unit” manual.
In chapter 5.1 of the manual “SIMATIC Panel PC 670/870 control unit” you will find
general information about the concept of the distributed configuration.
In Section You Will Find on Page
8.1 Description 8-2
8.2 Cable connection 8-4
8.3 Spare parts 8-4
8.4 Technical Data 8-4
