4.1.3 Functional Units Visible After Opening the Device
View
The function units become visible after removing the top cover of the unit and
removing the hard disk module.
Power supply unit
ProcessorWiring backplane Memory expansion module
Disk drive or LS 240
Fan
Figure 4-2 Computing unit open
