Configuring the Computing Unit in BIOS Setup
Release 04/02
5-7
Panel PC 670 Computing Unit, Equipment Manual
Primary Master, Primary Slave, Secondary Master, Secondary Slave
The system jumps to the following submenu when you select this type of menu
field:
PhoenixBIOS Setup Utility
Item Specific Help
Type:
ESC Exit
Select Item
Select Menu
+ / –
Select
Change Values
Sub-Menu
F9
F10
Setup Defaults
Save and Exit
[Auto] (recommended)
Autotypes installed
IDE-devices
[USER]
Enter parameters of
IDE-devices installed
at this connection
Enter
Help
F1
Main
Primary Master [20496 MB]
[ Auto ]
Maximum Capacity: 20496 MB
Multi-Sector Transfers: [16 Sectors]
LBA Mode Control:
[Enabled]
32 Bit I/O: [Enabled]
Transfer Mode: [FPIO 4 / DMA 2]
Ultra DMA Mode:
[Disabled]
LBA Format
Total Sectors: 40031712
Figure 5-3 Primary Master
Field Type
The parameters you can select here are normally stored on your IDE drive. The
’Auto’ setting in the Type field means that these values are automatically read
from the drive and written into memory (Autodetect).
If Type is selected for a drive that cannot be detected, a timer times out in
approximately 1 minute and the entries remain unchanged. You should always
check that the interfaces for which you select ’Auto’ are in fact connected to
drives.
Select “User” if you want to define the hard-disk type yourself, in which case
remember that you also have to set the other fields, including Cylinder, Heads,
Sectors/Track and WritePrecomp, to the correct values for the type of hard disk in
question.
