Siemens SIMATIC PC 670 - Connecting and Switching on the Computing Unit; Chapter Overview

3-1
Panel PC 670 Computing Unit, Equipment Manual
Connecting and Switching on the
Computing Unit
Chapter Overview
In Section You Will Find on Page
3.1 View of Interface Side 3-2
3.2 View of Drive Side 3-5
3.3 Connecting Peripheral Devices 3-6
3.4 Working with PC Cards 3-10
3.5 Drives 3-13
3.6 Backup battery 3-17
3.7 Using the Computing Unit in a SIMATIC S5 Network 3-18
3.8 Using the Computing Unit in a SIMATIC S7 Network (MPI/DP) 3-22
3.9 Networking the Computing Unit and Other Nodes via PROFIBUS 3-24
3.10 Networking the Computing Unit and Other Computers via
Industrial Ethernet
3-25
3.11 Connection under Windows 3-25
3
