Panel PC 670 Computing Unit, Equipment Manual
7.2 Overview of the Components and Interfaces
Component/
Port
Description Parameters
Chipset VIA PN133T S SDRAM
BIOS Update via software S 512K in 4 pages
CPU Pentium III / Celeron
(type FC-PGA370)
S Upgradeable
S Multimedia support
S On Board L2-Cache with 128 k/256 k
/512 K
Memory DIMM modules
up to max. 256MB/DIMM
S Data capacity of 64 bits + ECC
S Modules with ECC possible
S 3.3 V
S SDRAM to PC100 specification
S up to 128MBit chip size on the module
S 66/100MHz bus speed
S 2 DIMMs can be used
S Easy to replace
S variable from 64-512MB/DIMM
Graphics card UXGA LCD Controller on the AG Bus is
integrated Chip set (S3)
S up to 32 Mbytes of SDRAM are part of
the main memory and can be
configured (8/16/32MB)
S CRT:
up to1600x1200/85Hz 65536 colors
with PC133 memory modules
up to1280x1024/85Hz 65536 colors
with PC100 memory modules
Hard disk ATA-33 mode S Ultra DMA capable
CD-ROM drive Master on secondary EIDE channel S 24 speed
CD-RW/DVD Master on secondary EIDE channel Multi Spin Writer Drive
S Read: CD-ROM, CD-R 14-32 times,
CD-RW 8-20 times Speed
S Write: CD-R 12 times,
CD-RW 10 times Speed
suppors recording:
S Disc at once, Track at once,
Session at once, Packet writing
Floppy Notebook port for 34-pin ribbon cable S 1.44 MB
LS240 Slave on secondary EIDE channel S 1.44 MB standard floppy disks
S 120MB/240MB SuperDisk
Keyboard Port for PS2 keyboard S Standard
Mouse PS2 mouse port S Standard
Serial COM1/25 pins
COM2/9 pins.
S TTY *
2
and V24
S Standard
TTY Communication with SIMATIC S5-CPUs S Range up to 1000 m
