Configuring the Computing Unit in BIOS Setup
Release 04/02
5-26
Panel PC 670 Computing Unit, Equipment Manual
Groups marked + contain more than one device. When you select a group marked
in this way, hit Enter to view the list of devices in the group. See the figure below
for an illustration:
PhoenixBIOS Setup Utility
Item Specific Help
ESC Exit
Select Item
Select Menu
+ / –
Select
Change Values
Sub-Menu
F9
F10
Setup Defaults
Save and Exit
Enter
Help
F1
Advanced Security Version ExitMain Power
Keys used to view or
configure devices:
<Enter> expands or
collapses devices with
a + or –
<Ctrl+Enter> expands
all
<+> and <–> moves
the device up or down.
Boot Sequence
–Removable Devices
Legacy Floppy Drive
–Hard Drive
FUJITSU MPF3204AT-(PM)
Alternate Device
CD-ROM Drive
Figure 5-19 “Boot Sequence” Menu (Example)
This screen shows all possible boot devices; within a given group the highest
priority device is always listed first. Here again, you can change the sequence as
described above.
If a boot device is not available, the next device in the sequence is automatically
checked to ascertain whether it is bootable.
