Configuring the Computing Unit in BIOS Setup
Release 04/02
5-30
Panel PC 670 Computing Unit, Equipment Manual
System Parameters Your EntriesStandard Settings
Cardbus/PCMCIA Slot Enabled
SafeCard Functions Enabled
Legacy USB Support Disabled
CRT/LCD selection SIMULTAN
LCD Screensize Expanded
DSTN Contrast 154
PS2 Mouse Enabled
Advanced
COM/LPT Configuration
Internal COM1 Enabled
Base I/O address 3F8
Interupt IRQ4
Internal COM2 Enabled
Base I/O address 2F8
Interrupt IRQ3
Internal LPT1 Enabled
Mode Bi-directional
Base I/O address 378
Interrupt IRQ7
DMA Channel (only for ECP) DMA 3
PCI Configuration
PCI Device Slot 1
Option ROM Scan Enabled
Enable Master Enabled
Latency Timer 0040 h
PCI Device Slot 2
Option ROM Scan Enabled
Enable Master Enabled
Latency Timer 0040 h
PCI/PnP ISA IRQ Exclusuion
IRQ3 Available
IRQ4 Available
IRQ5 Available
IRQ9 Available
IRQ10 Available
IRQ11 Reserved
PCI IRQ Line 1 Auto Select
PCI IRQ Line 2 Auto Select
PCI IRQ Line 3 Auto Select
PCI IRQ Line 4 Auto Select
Installed O/S Other
Reset Configuration Data No
