Technical Data
Release 04/02
A-3
Panel PC 670 Computing Unit, Equipment Manual
Environmental conditions
Temperature
– operation
– storage/transport
– gradient
tested to DIN EN 60068-2-2:1994, DIN IEC 60068-2-1,
DIN IEC 60068-2-14,
+5 °C to +45 °C
- 20°C to +60°C
max 10°C/h (no condensation)
Relative humidity
– operation
– storage/transport
– gradient
tested to DIN IEC 60068-2-3, DIN IEC 60068-2-30,
DIN IEC 60068-2-56
5% to 80% at 25°C (no condensation)
5% to 95% at 25°C (no condensation)
max 10°C/h (no condensation)
Mechanical environmental conditions
Vibration *)
– operation
– storage/transport
tested to DIN IEC 60068-2-6
10 to 58 Hz: 0.075 mm, 58 to 500 Hz: 9.8 m/s
2
5 to 9 Hz: 3,5 mm, 9 to 500 Hz: 9.8 m/s
2
Shock
– operation
– storage/transport
tested to DIN IEC 60068-2-29
50 m/s
2
, 30 ms,
250 m/s
2
, 6 ms,
Special Features
Quality assurance to ISO 9001
Mainboard
Processor Intel Pentium III / Celeron (see order documentation)
Internal processor cache 2x 16KB first level, 128/256/512 KB second level,
dependent on the processor used
Main memory maximum 512 MB SDRAM,
memory configuration (see order documentation)
2. Level Cache Processor internal
Free expansion slots 1 shared ISA/PCI (max 175 mm long),
1 PCI (max 265mm long)
– max. permissible current input per ISA slot
– max. permissible current input per PCI slot
– in total (all slots)
5V 2A, 12V 0.3A, -12V 0.1A
5V 2A, 12V 0.3A, -12V 0.1A
5V 3A, 12V 0.6A, -12V 0.15A may not be exceeded
Drives
Floppy disk/LS240 drive 3.5” (1.44 MB) / 3.5” (240 MB, 120 MB or 1.44 MB)
Hard disk 3,5”, EIDE, UDMA33, hard disk capacity (see order
documentation)
CD-ROM-/CD-RW-/DVD(Combo) drive 650 MB / 4.7 GB
*) Restrictions for LS 240 with 120/240 MB data carrier and CD ROM /CD RW /DVD
10 to 58 Hz: 0.019 mm, 58 to 500 Hz: 2.5 m/s
2
