Maintenance and service
11.1 Removing and installing hardware components
SIMATIC Rack PC 840 V2
Operating Instructions, Edition 05/2006, A5E00248055-04
11-9
How to remove the fan
4. Remove the fan bracket from the
cubicle
5. Remove both fan connectors
6. Remove all fan screws and remove
the fan from the bracket
