Siemens Simatic S7-1500 CPU 1512C-1 PN User Manual

Wiring
4.3 Terminal and block diagrams
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
Manual, 12/2017, A5E40898741-AA
103
Input filter for digital inputs
To suppress disruptions, you can configure an input delay for the digital inputs.
You can specify the following values for the input delay:
● None
● 0.05 ms
● 0.1 ms
● 0.4 ms
● 1.6 ms
● 3.2 ms (default setting)
● 12.8 ms
● 20 ms
Note
Shielding
If you use standard digital inputs with "None" set as the input delay, you must use shielded
cables. Shielding and the infeed element are recommended for use of standard digital inputs
starting from an input delay of 0.05 ms but are not absolute
ly necessary.

Siemens Simatic S7-1500 CPU 1512C-1 PN Specifications

General

Integrated Interfaces	PROFINET
Data Memory	1 MB
Number of Signal Boards	1
Firmware Version	V2.8
Rated Value (DC)	24 V
Number of PROFINET Ports	2
Number of PROFINET Ports with Switch	2
Integrated Web Server	Yes
Number of Digital Inputs	16
Number of Digital Outputs	16
Number of Analog Outputs	2
Number of High-speed Counters	6
Program Memory	300 KB
Number of Signal Modules	32
Engineering with	STEP 7 Professional V13
Interface Type	Ethernet
Data Storage	Yes
Operating Temperature	0 to 60 °C
Dimensions	147 mm x 129 mm
