Siemens Simatic S7-1500 CPU 1512C-1 PN User Manual

CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
Manual, 12/2017, A5E40898741-AA
141
Technical specifications
7
Technical specifications of the CPU 1512C-1 PN
Article number
6ES7512-1CK01-0AB0
General information
Product type designation
CPU 1512C-1 PN
HW functional status
FS01
Firmware version
V2.5
Engineering with
• STEP 7 TIA Portal configurable/integrated
as of version
V15
Configuration control
via dataset
Yes
Display
Screen diagonal [cm] 3.45 cm
Control elements
Number of keys
8
Mode buttons
2
Supply voltage
Type of supply voltage
24 V DC
permissible range, lower limit (DC) 19.2 V; 20.4 V DC, for supplying the digital in-
puts/outputs
permissible range, upper limit (DC)
28.8 V
Reverse polarity protection
Yes
Mains buffering
• Mains/voltage failure stored energy time
5 ms; Refers to the power supply on the CPU
section
• Repeat rate, min.
1/s
Input current
Current consumption (rated value)
0.8 A
Current consumption, max.
1 A
Inrush current, max.
1.9 A; Rated value
I²t
0.34 A²·s
Digital inputs
• from load voltage L+ (without load), max.
20 mA; per group
Digital outputs
• from load voltage L+, max.
30 mA; Per group, without load

Siemens Simatic S7-1500 CPU 1512C-1 PN Specifications

General

Integrated Interfaces	PROFINET
Data Memory	1 MB
Number of Signal Boards	1
Firmware Version	V2.8
Rated Value (DC)	24 V
Number of PROFINET Ports	2
Number of PROFINET Ports with Switch	2
Integrated Web Server	Yes
Number of Digital Inputs	16
Number of Digital Outputs	16
Number of Analog Outputs	2
Number of High-speed Counters	6
Program Memory	300 KB
Number of Signal Modules	32
Engineering with	STEP 7 Professional V13
Interface Type	Ethernet
Data Storage	Yes
Operating Temperature	0 to 60 °C
Dimensions	147 mm x 129 mm
