Siemens Simatic S7-1500 CPU 1512C-1 PN User Manual

Parameters/address space
5.5 Output type and output ranges of the analog on-board I/O
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
Manual, 12/2017, A5E40898741-AA
121
5.5
Output type and output ranges of the analog on-board I/O
Introduction
The analog on-board I/O is set to voltage output type and output range ±10 V as default for
the outputs. If you want to use another output range or output type, you need to change the
parameter settings of the analog on-board I/O in STEP 7 (TIA Portal).
Output types and output ranges
The following table shows the output type and the corresponding output ranges.
Table 5- 4 Output type and output ranges
Output type
Output range
Voltage 1 to 5 V
0 to 10 V
±10 V
Current 0 to 20 mA
4 to 20 mA
±20 mA
Deactivated
-

Siemens Simatic S7-1500 CPU 1512C-1 PN Specifications

General

Integrated Interfaces	PROFINET
Data Memory	1 MB
Number of Signal Boards	1
Firmware Version	V2.8
Rated Value (DC)	24 V
Number of PROFINET Ports	2
Number of PROFINET Ports with Switch	2
Integrated Web Server	Yes
Number of Digital Inputs	16
Number of Digital Outputs	16
Number of Analog Outputs	2
Number of High-speed Counters	6
Program Memory	300 KB
Number of Signal Modules	32
Engineering with	STEP 7 Professional V13
Interface Type	Ethernet
Data Storage	Yes
Operating Temperature	0 to 60 °C
Dimensions	147 mm x 129 mm
