2.2 Hardware properties and firmware functions
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
Manual, 12/2017, A5E40898741-AA
21
2.2.1
Hardware properties of the CPU part
View of the CPU
The figure below shows the CPU part of the CPU 1512C-1 PN.
Figure 2-1 CPU 1512C-1 PN
Note
Protective film
Note that a protective film is attached to the display of the CPU when shipped from the
factory. Remove the protective film if necessary.
