Siemens Simatic S7-1500 CPU 1512C-1 PN User Manual

Product overview
2.2 Hardware properties and firmware functions
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
22 Manual, 12/2017, A5E40898741-AA
Properties
The CPU 1512C-1 PN has the following technical properties:
Property
Description
Additional information
CPU display
All CPUs of the SIMATIC S7-1500 product series fea-
ture a display with plain text information. The display
provides information on order numbers, firmware ver-
sion and serial numbers of all connected modules. In
addition, you can set the IP address of the CPU and
carry out further network settings. The display shows
occurring error messages directly in plain text.
In addition to the functions listed here, a multitude of
other functions that are described in the SIMATIC S7-
1500 Display Simulator are shown on the display.
• S7-1500, ET 200MP system
manual
(http://support.automation.sieme
ns.com/WW/view/en/59191792)
• SIMATIC S7-1500 Display Simu-
lator
(http://www.automation.siemens.
com/salesmaterial-as/interactive-
manuals/getting-started_simatic-
s7-1500/disp_tool/start_en.html)
Supply voltage
A 4-pole connection plug that is located at the front of
the CPU supplies the 24 V DC supply voltage.
• Chapter Wiring (Page 77)
• S7-1500, ET 200MP system
manual
(http://support.automation.sieme
ns.com/WW/view/en/59191792)
PROFINET IO
PROFINET interface (X1
P1 R and X1 P2 R)
The X1 interface has two ports (P1 R and P2 R). In
addition to basic PROFINET functionality, its also sup-
ports PROFINET IO RT (real time) and IRT (isochro-
nous real time), which means you can configure
PROFINET IO communication or real-time settings on
the interface.
Port 1 and Port 2 can also be used as ring ports for the
configuration of redundant ring structures in Ethernet
(media redundancy).
Basic PROFINET functionality comprises:
• HMI communication
• Communication with the configuration system
• Communication with a higher-level network (back-
bone, router, Internet)
•
Communication with another machine or automation
cell
PROFINET function manual
(http://support.automation.siemens.c
om/WW/view/en/68039307)
Operation of the CPU as
• IO controller
• I-device
•
IO controller:
As an IO controller the CPU addresses the con-
nected IO devices
•
I-device:
As an I-device (intelligent IO device) the CPU is as-
signed to a higher-level IO controller and is used in
the process as an intelligent pre-processing unit of
sub-processes

Siemens Simatic S7-1500 CPU 1512C-1 PN Specifications

General

Integrated Interfaces	PROFINET
Data Memory	1 MB
Number of Signal Boards	1
Firmware Version	V2.8
Rated Value (DC)	24 V
Number of PROFINET Ports	2
Number of PROFINET Ports with Switch	2
Integrated Web Server	Yes
Number of Digital Inputs	16
Number of Digital Outputs	16
Number of Analog Outputs	2
Number of High-speed Counters	6
Program Memory	300 KB
Number of Signal Modules	32
Engineering with	STEP 7 Professional V13
Interface Type	Ethernet
Data Storage	Yes
Operating Temperature	0 to 60 °C
Dimensions	147 mm x 129 mm
