Product overview
2.2 Hardware properties and firmware functions
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
20 Manual, 12/2017, A5E40898741-AA
2.2
Hardware properties and firmware functions
The CPU 1512C-1 PN consists of a CPU part, an analog on-board I/O module (X10) and a
digital on-board I/O module (X11 and X12). When configured in the TIA Portal, the compact
CPU therefore occupies a single shared slot (slot 1).
The properties and functions of the CPU part and the analog and digital on-board I/O
modules can be found in the subsections below. The
properties
describe the hardware
features of the CPU part and the analog and digital on-board I/O modules. The
functions
describe the functions of the firmware of the CPU part and the analog and digital on-board
I/O modules.
Article number
6ES7512-1CK01-0AB0
Accessories
The following accessories are included in the scope of delivery and can also be ordered
separately as spare parts:
● 3 x front connector (push-in terminals) including cable ties
● 3 x shield clamp
● 3 x shield terminal
● 3 x infeed element (push-in terminals)
● 3 x labeling strip
● 3 x universal front cover
For more information on accessories, refer to the S7-1500, ET 200MP system manual
(http://support.automation.siemens.com/WW/view/en/59191792).

Siemens Simatic S7-1500 CPU 1512C-1 PN Specifications

General

Integrated Interfaces	PROFINET
Data Memory	1 MB
Number of Signal Boards	1
Firmware Version	V2.8
Rated Value (DC)	24 V
Number of PROFINET Ports	2
Number of PROFINET Ports with Switch	2
Integrated Web Server	Yes
Number of Digital Inputs	16
Number of Digital Outputs	16
Number of Analog Outputs	2
Number of High-speed Counters	6
Program Memory	300 KB
Number of Signal Modules	32
Engineering with	STEP 7 Professional V13
Interface Type	Ethernet
Data Storage	Yes
Operating Temperature	0 to 60 °C
Dimensions	147 mm x 129 mm
