Wiring
4.3 Terminal and block diagrams
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
Manual, 12/2017, A5E40898741-AA
113
Technical characteristics of the outputs
The following table shows an overview of the technical characteristics of the individual
outputs.
Frequency range
(period duration)
DQ0 to DQ7
DQ8 to DQ15
High-speed output
(0.1 A) activated
High-Speed output
(0.1 A) deactivated
Standard output
max. 100 kHz max. 10 kHz max. 100 Hz
max. 0.1 A
max. 0.5 A
max. 0.5 A
Switching to P potential /
sink output
Switching to P potential
1)
Switching to P potential
1)
Accuracy of
the pulse
duration
10 to <= 100 kHz (100 to
> = 10 µs)
±100 ppm ±2 µs --- ---
100 Hz to <10 kHz (10
ms to > 100 µs)
±100 ppm ±10 µs with
load > 0.1 A
±100 ppm ±20 µs with
load ≥ 2mA
10 to < 100 Hz (0.1 s to
> 10 ms)
±100 ppm ±100 µs with
load > 0.1 A
±100 ppm ±200 µs with
load ≥ 2mA
1 to <10 Hz (1 to > 0.1 s) ±150 ppm ±2 µs ±150 ppm ±10 µs with
load > 0.1 A
±150 ppm ±20 µs with
load ≥ 2mA
±150 ppm ±100 µs with
load > 0.1 A
±150 ppm ±200 µs with
load ≥ 2mA
0.1 to < 1 Hz (10 to >1 s) ±600 ppm ±2 µs ±600 ppm ±10 µs with
load > 0.1 A
±600 ppm ± 20 µs with
load ≥ 2mA
±600 ppm ±100 µs with
load > 0.1 A
±600 ppm ±200 µs with
load ≥ 2mA
Accuracy of
the frequency
--- ± 100 ppm
2)
± 100 ppm
2)
± 100 ppm
2)3)
Minimum
pulse duration
2 µs 20 µs with load > 0.1 A
40 µs with load ≥ 2 mA
20 µs with load < 240 Ω
1)
400 µs with load > 0.1 A
500 µs with load ≥ 2 mA
400 µs with
load < 240 Ω
1)
1)
With sourcing outputs, it must be taken into
consideration that falling edges can be delayed as compared to rising edges
depending on the load. The on-load factor can therefore be falsified. Consider using a high-speed output if the load at
the output is greater than 240 Ω.
2)
The frequency has a basic accuracy of ±100 ppm with a resolution of 0.3638 mHz.
3)
Standard outputs are affected by jitter during generation of frequencies. The set period duration is not adhered to in
every period, but it is adhered to on average over several periods.

Siemens Simatic S7-1500 CPU 1512C-1 PN Specifications

General

Integrated Interfaces	PROFINET
Data Memory	1 MB
Number of Signal Boards	1
Firmware Version	V2.8
Rated Value (DC)	24 V
Number of PROFINET Ports	2
Number of PROFINET Ports with Switch	2
Integrated Web Server	Yes
Number of Digital Inputs	16
Number of Digital Outputs	16
Number of Analog Outputs	2
Number of High-speed Counters	6
Program Memory	300 KB
Number of Signal Modules	32
Engineering with	STEP 7 Professional V13
Interface Type	Ethernet
Data Storage	Yes
Operating Temperature	0 to 60 °C
Dimensions	147 mm x 129 mm
