Siemens Simatic S7-1500 CPU 1512C-1 PN User Manual

Parameters/address space
5.7 Parameters of the digital on-board I/O
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
126 Manual, 12/2017, A5E40898741-AA
Configurable parameters and default settings for inputs
Table 5- 10 Configurable parameters for inputs
Parameters
1)
Value range
Default
Reconfiguration in RUN
Diagnostics
• No
supply voltage L+
Yes/No No Yes
Input delay
None, 0.05 ms, 0.1 ms,
0.4 ms, 1.6 ms, 3.2 ms,
12.8 ms, 20 ms
3.2 ms Yes
Hardware interrupt
• Rising edge
Yes/No No Yes
• Falling edge
Yes/No No Yes
1)
All parameters can be set channel-selective
Configurable parameters and default settings for outputs
Table 5- 11 Configurable parameters for outputs
Parameters
1)
Value range
Default
Reconfiguration in RUN
Diagnostics
• Missing
supply voltage L+
Yes/No No Yes
Reaction to CPU STOP
When the digital output is controlled by a
technology channel (HSC, PTO or PWM),
this parameter is not effective. In this case
the technology channel specifies the reac-
tion of the digital output to CPU STOP.
• Turn off
• Keep last value
• Output substitute value 1
Turn off Yes
1)
All parameters can be set channel-selective

Siemens Simatic S7-1500 CPU 1512C-1 PN Specifications

General

Integrated Interfaces	PROFINET
Data Memory	1 MB
Number of Signal Boards	1
Firmware Version	V2.8
Rated Value (DC)	24 V
Number of PROFINET Ports	2
Number of PROFINET Ports with Switch	2
Integrated Web Server	Yes
Number of Digital Inputs	16
Number of Digital Outputs	16
Number of Analog Outputs	2
Number of High-speed Counters	6
Program Memory	300 KB
Number of Signal Modules	32
Engineering with	STEP 7 Professional V13
Interface Type	Ethernet
Data Storage	Yes
Operating Temperature	0 to 60 °C
Dimensions	147 mm x 129 mm
