Siemens Simatic S7-1500 CPU 1512C-1 PN User Manual

Technical specifications
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
Manual, 12/2017, A5E40898741-AA
149
Article number
6ES7512-1CK01-0AB0
Input ranges (rated values), currents
• 0 to 20 mA
Yes; Physical measuring range: ± 20 mA
• Input resistance (0 to 20 mA)
50 Ω; Plus approx. 55 ohm for overvoltage pro-
tection by PTC
• -20 mA to +20 mA
Yes
• Input resistance (-20 mA to +20 mA)
50 Ω; Plus approx. 55 ohm for overvoltage pro-
tection by PTC
• 4 mA to 20 mA
Yes; Physical measuring range: ± 20 mA
• Input resistance (4 mA to 20 mA)
50 Ω; Plus approx. 55 ohm for overvoltage pro-
tection by PTC
Input ranges (rated values), resistance thermome-
ter
• Ni 100
Yes; Standard/climate
• Input resistance (Ni 100)
10 MΩ
• Pt 100
Yes; Standard/climate
• Input resistance (Pt 100)
10 MΩ
Input ranges (rated values), resistors
• 0 to 150 ohms
Yes; Physical measuring range: 0 ... 600 ohms
• Input resistance (0 to 150 ohms)
10 MΩ
• 0 to 300 ohms
Yes; Physical measuring range: 0 ... 600 ohms
• Input resistance (0 to 300 ohms)
10 MΩ
• 0 to 600 ohms
Yes
• Input resistance (0 to 600 ohms)
10 MΩ
Cable length
• shielded, max.
800 m; for U/I, 200 m for R/RTD
Analog outputs
integrated channels (AO)
2
Voltage output, short-circuit protection
Yes
Cycle time (all channels), min. 1 ms; Dependent on the parameterized interfer-
ence frequency suppression; for details, see
conversion procedure in manual
Output ranges, voltage
• 0 to 10 V
Yes
• 1 V to 5 V
Yes
• -10 V to +10 V
Yes

Siemens Simatic S7-1500 CPU 1512C-1 PN Specifications

General

Integrated Interfaces	PROFINET
Data Memory	1 MB
Number of Signal Boards	1
Firmware Version	V2.8
Rated Value (DC)	24 V
Number of PROFINET Ports	2
Number of PROFINET Ports with Switch	2
Integrated Web Server	Yes
Number of Digital Inputs	16
Number of Digital Outputs	16
Number of Analog Outputs	2
Number of High-speed Counters	6
Program Memory	300 KB
Number of Signal Modules	32
Engineering with	STEP 7 Professional V13
Interface Type	Ethernet
Data Storage	Yes
Operating Temperature	0 to 60 °C
Dimensions	147 mm x 129 mm
