Parameter data records
B.7 Parameter data records of the high-speed counters
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
186 Manual, 12/2017, A5E40898741-AA
Bit →
7
6
5
4
3
2
1
0
Byte
50
Use of
HSC DI1
Reserved = 0
1)
Selection HSC DI1
Value range (applicable if the CPU is configured with deactivated
'Front connector assignment like 1511C' setting):
HSC1..3:
01000
B
: Front connector X11, terminal 11 (DI8)
01001
B
: Front connector X11, terminal 12 (DI9)
01010
B
: Front connector X11, terminal 13 (DI10)
01011
B
: Front connector X11, terminal 14 (DI11)
01100
B
: Front connector X11, terminal 15 (DI12)
01101
B
: Front connector X11, terminal 16 (DI13)
01110
B
: Front connector X11, terminal 17 (DI14)
01111
B
: Front connector X11, terminal 18 (DI15)
HSC4..6:
11000
B
: Front connector X12, terminal 11 (DI8)
11001
B
: Front connector X12, terminal 12 (DI9)
11010
B
: Front connector X12, terminal 13 (DI10)
11011
B
: Front connector X12, terminal 14 (DI11)
11100
B
: Front connector X12, terminal 15 (DI12)
11101
B
: Front connector X12, terminal 16 (DI13)
11110
B
: Front connector X12, terminal 17 (DI14)
11111
B
: Front connector X12, terminal 18 (DI15)
All other values: Reserved
Note: If the CPU with enabled 'Front connector assignment like
1511C' setting is configured, the parameter data record definition of
CPU 1511C applies. See device manual of CPU 1511C.
0
B
: Not
used
1
B
: Used
51
Use of
HSC DQ1
Reserved = 0
1)
Selection HSC DQ1
Value range:
HSC1:
00001
B
: Front connector X11, terminal 22 (DQ1)
01001
B
: Front connector X11, terminal 32 (DQ9)
HSC2:
00011
B
: Front connector X11, terminal 24 (DQ3)
01011
B
: Front connector X11, terminal 34 (DQ11)
HSC3:
00100
B
: Front connector X11, terminal 25 (DQ4)
01100
B
: Front connector X11, terminal 35 (DQ12)
HSC4:
00101
B
: Front connector X11, terminal 26 (DQ5)
01101
B
: Front connector X11, terminal 36 (DQ13)
HSC5:
00111
B
: Front connector X11, terminal 28 (DQ7)
01111
B
: Front connector X11, terminal 38 (DQ15)
HSC6:
00110
B
: Front connector X11, terminal 27 (DQ6)
01110
B
: Front connector X11, terminal 37 (DQ14)
All other values: Reserved
0
B
: Not
used
1
B
: Used
1)
Reserved bits must be set to 0
