Siemens Simatic S7-1500 CPU 1512C-1 PN User Manual

Product overview
2.2 Hardware properties and firmware functions
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
Manual, 12/2017, A5E40898741-AA
29
Properties of the analog outputs
The 2 outputs of the analog on-board I/O module have the following properties:
Property
Description
Additional information
Resolution: 16 bits includ-
ing sign
Once the CPU has processed the digital signal, a DAC
(digital-to-analog converter) integrated in the analog on-
board I/O module converts the output signal to an ana-
log current or voltage value. The resulting value of the
output signal corresponds to the output value with
which the analog on-board I/O module controls the
analog actuators.
• Chapter Analog value pro-
cessing
•
Analog value processing function
manual
(http://support.automation.sieme
ns.com/WW/view/en/67989094)
Integrated output types
With the selection of the type of output you specify
whether the digital-to-analog converter is to convert the
output signal into the type of output "Current" or "Volt-
age". The output can be selected by individual channel.
Configurable diagnostics
The analog on-board I/O module can diagnose errors.
The module reports the diagnosed state to the CPU
using a diagnostics error interrupt. Different types of
diagnostics are available that you can parameterize
channel-granularly.
Chapter Parameters of the analog
on-board I/O (Page 122)

Siemens Simatic S7-1500 CPU 1512C-1 PN Specifications

General

Integrated Interfaces	PROFINET
Data Memory	1 MB
Number of Signal Boards	1
Firmware Version	V2.8
Rated Value (DC)	24 V
Number of PROFINET Ports	2
Number of PROFINET Ports with Switch	2
Integrated Web Server	Yes
Number of Digital Inputs	16
Number of Digital Outputs	16
Number of Analog Outputs	2
Number of High-speed Counters	6
Program Memory	300 KB
Number of Signal Modules	32
Engineering with	STEP 7 Professional V13
Interface Type	Ethernet
Data Storage	Yes
Operating Temperature	0 to 60 °C
Dimensions	147 mm x 129 mm
