Product overview
2.2 Hardware properties and firmware functions
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
Manual, 12/2017, A5E40898741-AA
35
Functions of the digital outputs
The digital outputs of the digital on-board I/O module have the following functions:
The high-speed digital outputs of the digital on-board
I/O module support technology functions such as fast
counting, measuring, position detection and pulse
generators (PWM, PTO and frequency output). Due
to the supported technology functions, the compact
CPUs are suitable for controlling pumps, fans, mixers,
conveyor belts, lifting platforms, gate control systems,
building management systems, synchronized axes,
Chapter Technology functions
(Page 42)
You have the op
tion of reassigning parameters for the
digital on-board I/O module in RUN (for example,
behavior during CPU STOP, without affecting the
other channels).
• Chapter
Parameters of the digital
on-board I/O (Page 125)
• Chapter Parameter assignment
and structure of the parameter
data records of the digital on-
board I/O (Page 175)
Support of the value status
(Quality Information, QI)
Value status = 1 ("Good") indicates that the process
value specified by the user program is correctly out-
put at the terminal.
Value status = 0 ("Bad") indicates that the process
value output at the hardware output is incorrect or the
channel is used for technology functions.
Chapter Address space of the digital
on-board I/O (Page 116)
