Product overview
2.3 Operator controls and display elements
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
Manual, 12/2017, A5E40898741-AA
39
Slot for the SIMATIC memory card
PROFINET IO interface (X1) with 2 ports
Connection for supply voltage
Figure 2-7 View of the CPU 1512C-1 PN – bottom
