Siemens Simatic S7-1500 CPU 1512C-1 PN User Manual

Technology functions
3.2 Pulse generators
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
72 Manual, 12/2017, A5E40898741-AA
Interpretation of the SLOT parameter value
The value written in the SLOT parameter is displayed as in the table below depending on the
LD_SLOT value and the mode is interpreted.
LD_SLOT
Meaning of SLOT value
Valid modes for using the SLOT
value
SLOT data type
0
No action / idling
All operating modes
1 Period duration PWM UDInt
Permissible value
range*:
Minimum value: 10 µs,
100 µs or 10 000 µs
(10 ms)
Maximum value:
10 000 000 µs (10 s)
* The permissible value range depends on the selected hardware output and sometimes on the high
-speed mode (high-
speed/standard).

Siemens Simatic S7-1500 CPU 1512C-1 PN Specifications

General

Integrated Interfaces	PROFINET
Data Memory	1 MB
Number of Signal Boards	1
Firmware Version	V2.8
Rated Value (DC)	24 V
Number of PROFINET Ports	2
Number of PROFINET Ports with Switch	2
Integrated Web Server	Yes
Number of Digital Inputs	16
Number of Digital Outputs	16
Number of Analog Outputs	2
Number of High-speed Counters	6
Program Memory	300 KB
Number of Signal Modules	32
Engineering with	STEP 7 Professional V13
Interface Type	Ethernet
Data Storage	Yes
Operating Temperature	0 to 60 °C
Dimensions	147 mm x 129 mm
