Siemens Simatic S7-1500 CPU 1512C-1 PN User Manual

Wiring
4.2 PROFINET interfaces
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
Manual, 12/2017, A5E40898741-AA
79
Assignment of the MAC addresses
The CPU 1512C-1 PN has a PROFINET interface with two ports. The PROFINET interface
itself has a MAC address, and each of the two PROFINET ports has its own MAC address.
The CPU 1512C-1 PN therefore has three MAC addresses in total.
The MAC addresses of the PROFINET ports are needed for the LLDP protocol, for example
for the neighborhood discovery function.
The number range of the MAC addresses is continuous. The first and last MAC address are
lasered on the rating plate on the right side of each CPU 1512C-1 PN.
The table below shows how the MAC addresses are assigned.
Table 4- 1 Assignment of the MAC addresses
Assignment
Labeling
MAC address 1
PROFINET interface X1
(visible in STEP 7 for accessible devic-
es)
• Front, lasered
• Right side, lasered
(start of number range)
MAC address 2
Port X1 P1 R (required for LLDP, for
example)
• Front and right side, not lasered
MAC address 3
Port X1 P2 R (required for LLDP, for
example)
• Front, not lasered
• Right side, lasered
(end of number range)

Siemens Simatic S7-1500 CPU 1512C-1 PN Specifications

General

Integrated Interfaces	PROFINET
Data Memory	1 MB
Number of Signal Boards	1
Firmware Version	V2.8
Rated Value (DC)	24 V
Number of PROFINET Ports	2
Number of PROFINET Ports with Switch	2
Integrated Web Server	Yes
Number of Digital Inputs	16
Number of Digital Outputs	16
Number of Analog Outputs	2
Number of High-speed Counters	6
Program Memory	300 KB
Number of Signal Modules	32
Engineering with	STEP 7 Professional V13
Interface Type	Ethernet
Data Storage	Yes
Operating Temperature	0 to 60 °C
Dimensions	147 mm x 129 mm
