4.11 Planning subnets
S7-300, CPU 31xC and CPU 31x: Installation
Operating Instructions, Edition 08/2004, A5E00105492-05
4-51
Automation Solution with PROFINET CBA
Engineering
Human-Machine
Interface
Industrial Ethernet
PROFIBUS
Intelligent
Field devices
Mechanical +
Electrical/Elektronic +
User program
IE/PB-Link
Figure 4-5 New: Modular Concept with Distributed Intelligence
