Page #97 background imageLoading...
Page #97 background image
Installing
5.4 Labeling the modules
S7-300, CPU 31xC and CPU 31x: Installation
Operating Instructions, Edition 08/2004, A5E00105492-05
5-9
5.4 Labeling the modules
Slot numbers Assignment
You should assign a slot number to each one of the mounted modules, thus making it easier
to assign the modules in the configuration table in STEP 7. The table below shows the slot
number assignment.
Table 5-4 Slot numbers for S7 modules
Slot number Module Comment
1 Power supply (PS)
2 CPU
3 Interface module (IM) to the right of the CPU
4 1. Signal module (SM) to the right of the CPU or IM
5 2. Signal module (SM)
6 3. Signal module (SM)
7 4. Signal module (SM)
8 5. Signal module (SM)
9 6. Signal module (SM)
10 7. Signal module (SM)
11 8. Signal module (SM)
