Configuring
4.11 Planning subnets
S7-300, CPU 31xC and CPU 31x: Installation
Operating Instructions, Edition 08/2004, A5E00105492-05
4-55
Product range for the RJ45 connection
The following prefabricated twisted-pair cables are available:
Table 4-25 Data for twisted-pair patch cables
Cable designation Application Available
lengths
Order number
TP Cord RJ45/RJ45 TP connecting cable with two RJ45
connectors.
0.5 m
1.0 m
2.0 m
6.0 m
10.0 m
6XV1 850-2GE50
6XV1 850-2GH10
6XV1 850-2GH20
6XV1 850-2GH60
6XV1 850-2GN10
TP XP cord RJ45/RJ45 Crossed TP cable with two RJ45
connectors.
0.5 m
1.0 m
2.0 m
6.0 m
10.0 m
6XV1 850-2HE50
6XV1 850-2HH10
6XV1 850-2HH20
6XV1 850-2HH60
6XV1 850-2HN10
TP cord 9/RJ45 TP cable with a 9-pin Sub-D connector
and an RJ45 connector.
0.5 m
1.0 m
2.0 m
6.0 m
10.0 m
6XV1 850-2JE50
6XV1 850-2JH10
6XV1 850-2JH20
6XV1 850-2JH60
6XV1 850-2JN10
TP XP cord 9/RJ45 Cross-over TP patch cable with 9-pin
sub-D connector and RJ45 connector.
0.5 m
1.0 m
2.0 m
6.0 m
10.0 m
6XV1 850-2ME50
6XV1 850-2MH10
6XV1 850-2MH20
6XV1 850-2MH60
6XV1 850-2MN10
TP patch cable
9-45/RJ45
TP patch cable with RJ45 connector and
sub-D connector, with 45° cable exit (for
OSM/ESM only)
1.0 m 6XV1 850-2NH10
TP XP patch cable
9-45/RJ45
Cross-over TP patch cable with RJ45
connector and sub-D connector with 45°
cable exit (for OSM/ESM only)
1.0 m 6XV1 850-2PH10
TP XP patch cable 9/9 Cross-over TP patch cable for direct
connection of two industrial Ethernet
network components with ITP interface,
with two 9-pin sub-D connectors
1.0 m 6XV1 850-2RH10
TP patch cable
RJ45/15
TP patch cable with 15-pin sub-D
connector and RJ45 connector.
0.5 m
1.0 m
2.0 m
6.0 m
10.0 m
6XV1 850-2LE50
6XV1 850-2LH10
6XV1 850-2LH20
6XV1 850-2LH60
6XV1 850-2LNN10
TP XP patch cable
RJ45/15
Cross-over TP patch cable with 15-pin
sub-D connector and RJ45 connector
0.5 m
1.0 m
2.0 m
6.0 m
10.0 m
6XV1 850-2SE50
6XV1 850-2SH10
6XV1 850-2SH20
6XV1 850-2SH60
6XV1 850-2SN10
