4.3 Component dimensions
S7-300, CPU 31xC and CPU 31x: Installation
4-4 Operating Instructions, Edition 08/2004, A5E00105492-05
4.3 Component dimensions
Length of the mounting rails
Table 4-1 Mounting rails - Overview
Mounting rail length Usable length for modules Order number
160 mm 120 mm 6ES7 390-1AB60-0AA0
482.6 mm 450 mm 6ES7 390-1AE80-0AA0
530 mm 480 mm 6ES7 390-1AF30-0AA0
830 mm 780 mm 6ES7 390-1AJ30-0AA0
2000 mm cut to length as required 6ES7 390-1BC00-0AA0
In contrast to other rails, the 2 m mounting rail is not equipped with any fixing holes. These
must be drilled, allowing optimal adaptation of the 2 m rail to your application.
Dimensions of modules
Table 4-2 Module width
Module Width
Power supply module PS 307, 2 A 50 mm
Power supply module PS 307, 5 A 80 mm
Power supply module PS 307, 10 A 200 mm
CPU For information on assembly dimensions,
refer to the Technical Data in
CPU 31xC and
CPU 31x Manual, Technical Data
.
Analog I/O modules 40 mm
Digital I/O modules 40 mm
Simulator module SM 374 40 mm
Interface modules IM 360 and IM 365 40 mm
Interface module IM 361 80 mm
• Module height: 125 mm
• Module height with shielding contact element: 185 mm
• Maximum assembly depth: 130 mm
• Maximum assembly depth of a CPU with an inserted DP connector with angled cable
feed: 140 mm
• Maximum assembly depth with open front panel (CPU): 180 mm
Dimensions of other modules such as CPs, FMs etc. are found in the relevant manuals.
