Memory concept
6.2 Memory functions
Deleting blocks
When you delete a block, it is deleted from load memory. In STEP 7 , you can also delete
blocks with the user program (DBs also with SFC 23 "DEL_DB").
RAM used by this block is released.
Caution
If you delete a technology data block, the associated drive stops.
Remedy: Switch the CPU to STOP before you delete the technology data block.
Compression
When data are compressed, gaps which have developed between memory objects in load
memory/RAM as a result of load/delete operations will be eliminated. This releases free
memory in a continuous block.
Data compression is possible when the CPU is in RUN or in STOP.
Promming
When writing the RAM content to ROM, the actual values of the DBs are transferred from
RAM to load memory to form the start values for the DBs.
Note
This function is only permitted when the CPU is in STOP mode.
Load memory is cleared if the function could not be completed due to power loss.
S7-300 CPU Data: CPU 315T-2 DP
6-12 Manual, 12/2005, A5E00427933-02

Siemens SIMATIC S7-300 CPU Data: CPU 315-T-2 DP Specifications

General

Programming Language	STEP 7
Power Supply	24 V DC
Number of DP masters	1
Processable Technology objects	Yes
Number of counters	256
Number of timers	256
S7 communication	Yes
Number of connections for S7 communication, max.	16
PG/OP communication	Yes
Global data communication	Yes
Integrated DP interface	Yes
Integrated PROFINET interface	No
SIMATIC Computing Platform	No
Operating Temperature	0 to 60 °C
Integrated Interfaces	MPI, DP
Communication	PROFIBUS DP
Cycle Time	0.1 ms
Engineering with	STEP 7
Backup available	Yes
Transmission rate, max.	12 Mbit/s
