Product Description
1.2 Components Required for a Point-to-Point Connection with the CP 440
Point-to-point connection CP 440 Installation and Parameter Assignment
16 Manual, 09/2007, A5E00057742-03
1.2.2 Required Software Components
Software Components
The following table lists the software components required for establishing a point-to-point
connection with the CP 440.
Table 1-3 Software Components for a Point-to-Point Connection with the CP 440
Components Function Diagram
Software package STEP 7,
Version 4.02 or higher
... configures, assigns parameters,
programs and tests the S7-400.
CP 440: Point-to-Point Communication,
Parameter Assignment interface,
Version 5.1
... assigns parameters for the interfaces
of the CP 440.
Function blocks (FBs) with programming
examples
... control communication between the
CPU and the CP 440.
1.2.3 Incompatible CPU versions
CPU versions
The CP 440 can be operated with all CPU versions except the CPUs listed in the tables
below:
Table 1-4 CPU Versions with Which the CP 440 Can Be Used as of the Version Indicated
CPU MLFB
CPU 412-1 6ES7 412-1XF01-0AB0, Release 5
CPU 413-1 6ES7 413-1XG01-0AB0, Release 5
CPU 413-2 6ES7 413-2XG01-0AB0, Release 5
CPU 414-1 6ES7 414-1XG01-0AB0, Release 5
CPU 414-2 with 128k 6ES7 414-2XG01-0AB0, Release 5
CPU 414-2 with 348k 6ES7 414-2XJ00-0AB0, Release 7
CPU 416-1 6ES7 416-1XJ01-0AB0, Release 5
CPU 416-2 with 0.8 M 6ES7 416-2XK00-0AB0, Release 7
CPU 416-2 with 1.6 M 6ES7 416-2XL00-0AB0, Release 7
CPU 416-2 DP ISA Lite
CPU 416-2 DP ISA
CPU 412-2 DP PCI
CPU 416-2 DP PCI
6ES7 616-2PK00-0AB4, Release 3
