Assigning Parameters to and Calling the S7-Graph FB
S7-GRAPH for S7-300/400 Programming Sequential Control Systems
C79000-G7076-C526-01
9-3
You can also modify existing parameter sets in the variable declaration window.
You can, for example, delete unnecessary parameters from a standard parameter
set. System parameters cannot be modified however you can define user-specific
parameters to meet your requirements.
Note
Defined parameter names must not be used as step names (and vice-versa).
9.4 Parameter Sets of the FB
FB Sequencer
BOOL INIT_SQ
EN ENO
DB Sequencer
BOOL
BOOL
Minimum
FB Sequencer
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
INT
BOOL
BOOL
BOOL
INT
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
S_NO
S_MORE
S_ACTIVE
ERR_FLT
AUTO_ON
TAP_ON
MAN_ON
OFF_SQ
INIT_SQ
ACK_EF
S_PREV
S_NEXT
SW_AUTO
SW_TAP
SW_MAN
S_ON
S_OFF
T_PUSH
S_SEL
EN ENO
DB Sequencer
BOOL
BOOL
Standard
