5.5 Opening an S7-Graph FB or an S7-Graph Source File
You can open an S7-Graph FB or an S7-Graph source file either in the SIMATIC
Manager or in S7-Graph.
Note
If you create a new FB in S7-Graph, this is opened directly.
Opening in the SIMATIC Manager
In the SIMATIC Manager, follow the steps outlined below:
• Select the required object in the blocks or source files folder and double-click to
open it.
Opening in the S7-Graph Editor
In the S7-Graph editor, follow the steps outlined below:
1. Select the menu command File > Open or click the corresponding button.
2. In the dialog box that then appears, select the block or source file you want to
open. Decide whether you want to open a block on the programming device
(offline) or directly on the CPU (online).
