3 Designing a Sequential Control System
based on the Example of a Drill
Welcome to the S7-Graph Beginner’s Example
If you take an hour to work through the beginner’s example, you will learn how to
create a sequential control system for automating the drill as described below.
You first learn how to configure a sequential control system efficiently and will then
be guided step by step through the tasks you need to perform in the SIMATIC
Manager and in S7-Graph so that you can
• create the sequential control system,
• download it to the CPU
• and test it.
The correctly programmed sample is supplied with S7-Graph as a project called
"ZEn02_01_S7Graph_Drill".
