Siemens SIMATIC S7-GRAPH User Manual

Overview of All Actions
S7-GRAPH for S7 300/400 Programming Sequential Control Systems
13-18 C79000-G7076-C526-01
13.4 Timers in Actions
These actions are executed once when the event occurs and the corresponding
step is active. When the sequencer is run through after this, an event-dependent
action is executed again only when the event occurs again.
Action Explanation
Event In-
struc-
tion
Address Location Address
range
S1: Timers in actions linked with activation of a step
S1 TL T
<time>
X As soon as the step becomes active (enters state)
the timer starts. For the specified time, the timer bit
(status of the timer) is set to 1, when the time
elapses, it is reset to 0.
x = no.
of timer
S1 TD T
<time>
X As soon as the step becomes active (enters state)
the timer starts. For the specified time, the timer bit
(status of the timer) is set to 0, when the time
elapses, it is set to 1.
x = no.
of timer
S1 TR T
<time>
X As soon as the step becomes active (enters state)
the timer stops. Timer bit (status of the timer) and
timer value are reset to 0.
x = no.
of timer
S1 TLC T
<time>
X As soon as the step becomes active and the
condition (interlock) is satisfied, the timer starts. For
the specified time, the timer bit (status of the timer)
is set to 1, when the time elapses, it is reset to 0.
x = no.
of timer
S1 TDC T
<time>
X As soon as the step becomes active and the
condition (interlock) is satisfied, the timer starts. For
the specified time, the timer bit (status of the timer)
is set to 0, when the time elapses, it is set to 1.
x = no.
of timer
S1 TRC T
<time>
X As soon as the step becomes active and the
condition (interlock) is satisfied, the timer stops.
Timer bit (status of the timer) and timer value are
reset to 0.
x = no.
of timer
S0: Timers in actions linked with deactivation of a step
S0 TL T
<time>
X As soon as the step is deactivated (leaves state)
the timer starts. For the specified time, the timer bit
(status of the timer) is set to 1, when the time
elapses, it is reset to 0.
x = no.
of timer
S0 TD T
<time>
X As soon as the step is deactivated (leaves state)
the timer starts. For the specified time, the timer bit
(status of the timer) is set to 0, when the time
elapses, it is set to 1.
x = no.
of timer
