Siemens SIMATIC S7-GRAPH User Manual

Overview of All Actions
S7-GRAPH for S7-300/400 Programming Sequential Control Systems
C79000-G7076-C526-01
13-17
Action Explanation Address
range
Event In-
struc-
tion
Address
Area
Location
R1: Counters in actions linked to setting a registration
R1 CS C
<initial
counter
value>
X As soon as a registration is set, the initial
counter value is loaded in the counter.
x = counter
number
R1 CU C X As soon as a registration is set, the counter is
incremented by 1.
x = counter
number
R1 CD C X As soon as a registration is set, the counter is
decremented by 1.
x = counter
number
R1 CR C X As soon as a registration is set, the counter is
reset to 0.
x = counter
number
R1 CSC C
<initial
counter
value>
X As soon as a registration is set and the
condition (interlock) is satisfied, the initial
counter value is loaded in the counter.
x = counter
number
R1 CUC C X As soon a registration is set and the condition
(interlock) is satisfied, the counter is
incremented by 1.
x = counter
number
R1 CDC C X As soon a registration is set and the condition
(interlock) is satisfied, the counter is
decremented by 1.
x = counter
number
R1 CRC C X As soon as a registration is set and the
condition (interlock) is satisfied, the counter is
reset to 0.
x = counter
number
