Assigning Parameters to and Calling the S7-Graph FB
S7-GRAPH for S7-300/400 Programming Sequential Control Systems
C79000-G7076-C526-01
9-9
Parameter Data
Type
Description Min. Std. Max. User-
def.
SQ_HALTED BOOL SEQUENCE_IS_HALTED:
Sequencer stopped
áá
TM_HALTED BOOL
TIMES_ARE_HALTED:
Timers stopped
áá
OP_ZEROED BOOL
OPERANDS_ARE_ZEROED:
Addresses reset
áá
IL_ENABLED BOOL
INTERLOCK_IS_ENABLED:
Interlock enabled
áá
SV_ENABLED BOOL SUPERVISION_IS_ENABLED:
Supervision enabled
áá
ACKREQ_EN
ABLED
BOOL
ACKNOWLEDGE_REQUIRED_IS_
ENABLED:
Mandatory acknowledgment activated
á
SSKIP_EN
ABLED
BOOL STEP_SKIPPING_IS_ENABLED:
Skip step activated
á
SACT_DISP BOOL ACTIVE_STEPS_WERE_DISPLAYED:
Display active steps only in S_NO
á
SEF_DISP BOOL STEPS_WITH_ERROR_FAULT_WERE_
DISPLAYED:
Display only steps with error and disturbed
steps in S_NO
á
SALL_DISP BOOL
ALL_STEPS_WERE_DISPLAYED:
Display all steps in S_NO
á
AUTO_ON BOOL AUTOMATIC_IS_ON:
Indicates the automatic mode
ááá
TAP_ON BOOL
T_AND_PUSH_IS_ON:
Indicates the inching mode
ááá
TOP_ON BOOL
T_OR_PUSH_IS_ON:
Display SW_TOP mode
á
MAN_ON BOOL
MANUAL_IS_ON:
Indicates the manual mode
ááá
Parameter Set: Min. = Minimum; Std. = Standard; Max. = Maximum; User-def. = User-defined
