Instance DB
S7-GRAPH for S7 300/400 Programming Sequential Control Systems
15-8 C79000-G7076-C526-01
Parameter Description Data
Type
Read
int.
Write int. Read
Ext.
Write Ext.
IL_ENABLED
INTERLOCK_IS_ENABLED:
Interlocks not deactivated
BOOL yes no yes no
SV_ENABLED
SUPERVISION_IS_ENABLED:
Supervisions not deactivated
BOOL yes no yes no
ACKREQ_EN
ABLED
ACKNOWLEDGE_REQUIRED_IS_
ENABLED:
Mandatory acknowledgment
activated
BOOL yes no yes no
SSKIP_EN
ABLED
STEP_SKIPPING_IS_ENABLED:
Skip step activated
BOOL yes no yes no
SACT_DISP ACTIVE_STEPS_WERE_DISPLAYE
D
Display list with active steps only
BOOL yes no yes no
SEF_DISP STEPS_WITH_ERROR_FAULT_
WERE_DISPLAYED:
Display list only with steps with
error and disturbed steps
BOOL yes no yes no
SALL_DISP ALL_STEPS_WERE_DISPLAYED:
Display list with all steps
BOOL yes no yes no
AUTO_ON
AUTOMATIC_IS_ON:
Indicates the automatic mode
BOOL yes no yes no
TAP_ON
T_AND_PUSH_IS_ON:
Indicates the inching mode
BOOL yes no yes no
TOP_ON
T_OR_PUSH_IS_ON:
Display SW_TOP mode
BOOL yes no yes no
MAN_ON
MANUAL_IS_ON:
Indicates the manual mode
BOOL yes no yes no
