Siemens SIMATIC S7-GRAPH User Manual

Instance DB
S7-GRAPH for S7 300/400 Programming Sequential Control Systems
15-22 C79000-G7076-C526-01
n-26 PRS_INPAR:
Range of input parameters
DWORD 1
n-22 PRS_OUTPAR:
Range of output parameters
DWORD 1
n-18 SQ_FLAGS
Compiler flags part 1
WORD 6
n-6 SQ_FLAGS
Compiler flags part 2
Bit .0 == 1 --> condition descriptions
exist
BYTE 1
n-5 SQ_FLAGS
Compiler flags part 3
BYTE 1
n-4 G7_FBMARK:
Compatibility FB criteria analysis
(010 == 1.0)
BYTE 1
n-3 G7_RELEASE:
Graph version number (010 == 1.0)
BYTE 1
n-2 G7_ID2:
Graph ID ("7")
BYTE 1
n-1 G7_ID1:
Graph ID ("G")
BYTE 1
n = Length of the instance DB in bytes
