Setting Up and Operating the SIMATIC Rack PC IL 40 S
3-4
SIMATIC Rack PC IL 40 SManual
A5E00200171-01
483
465.1
101.6
176.5
19.01
18.31
6.94
4
433.5
449.04
492.54
17.06
17.68
19.39
Upwards for
vertical
installation
Upwards for
vertical
installation
Dimensions:
mm
Inch
Figure 3-1 Dimension Drawings for Installation
